One To One

Routing between one thermal port and a selected multiple thermal port

Description

The One To One component models routing between one thermal port and a vectorized multiple thermal port.

The number of nodes of multi_port  can be set using the Nodes parameter.

According to the order list defined by the parameter Select Node, only a selected multi_porti is connected to one other port.

The following image illustrates the behavior of the One To One routing component in the case of Select Node=2.

Connections

Name

Description

Modelica ID

port

Thermal port

port

multi_porti

i-th multiple thermal port

multi_port[i]

Parameters

Symbol

Default

Units

Description

Modelica ID

Nodes

2

Number of nodes

numNode

Select Node

2

The order of the selected node

SelectedNode
