Pacejka 2012

Tire component with Pacejka 2012 formulation and visualization

Description

The Pacejka 2012 tire component employs the 2012 formulation of the Pacejka tire model, presented in [1].

The tire geometry is assumed to be a thin circular disk, which is common in automotive applications. A single point contact is considered for the tire-ground interaction.

The tire kinematics used in this component are described in detail in Tire Kinematics.

Several options are available for defining the surface on which the tire is operating. These options are explained in Surface.

Details

Tire Parameters Block

The Pacejka 2012 tire model has about 180 parameters. Unlike the Linear and the Fiala tire components, where the required parameters are defined in the GUI, to facilitate the parameter handling process the Pacejka Parameters App should be used to generate a parameter block which contains the necessary tire parameters. To open this app, browse to Add Apps or Templates > Tires > Pacejka Parameters. The generated parameter block will be located in the Local Components panel on the left side of the GUI.

The user should place the generated parameter block into the workspace at the same or higher level as the Pacejka tire components that it defines.

Override Parameters

There is an Override check box in the Inertia, Radial Compliance, and Scaling Factors sections of the Pacejka tire component properties.

Enabling one of these check boxes allows the user to override the associated parameters otherwise defined in the tire parameters block. For example, the user can override the inertia properties as shown below.

Checking an Override check box also exposes the associated parameters to apps such as the Parameter Sweep app and the FMU Generation app.

ISO Axis

Unlike the Linear and Fiala tire models, the Pacejka tire model is typically asymmetric, that is $F_{x} (- κ) \neq - F_{x} (κ)$ or $F_{y} (- α) \neq - F_{y} (α)$ . To ensure the correct formulation, the ISO X axis of a tire should point towards the heading of the vehicle. The Show ISO axis option in the visualization section of the tire parameters can be helpful to visually confirm that the ISO axes have been assigned correctly.

If not assigned correctly, the user can change the integer parameter of ISO from 0 to 1 to rotate the ISO axis 180 degrees around ISO Z.

Sideness

The Pacejka tire parameters apply to a specific tire side. This denotes the side of the vehicle where the tire should be mounted. The Side parameter in the properties can be used to mirror the tire. For example, if the parameters of the generated parameter block are for a right side tire, then the tire components mounted on the right side of the vehicle model should be used with $Side = 0$ , and those on the left side should have $Side = 1$ .

Normal Force and Effective Radius

The normal force exerted by the surface to the tire is calculated using the given compliance parameters and surface geometry. There are two implemented formulations in the Pacejka tire component for calculating the normal force: Pacejka formulation and Linear spring-damper.

Pacejka Formulation

The Pacejka formulation option uses the following equation for the normal force [1]

$F_{z} = \{1 + q_{V2} |Ω| \frac{R_{0}}{V_{0}} - {(q_{Fcx} \frac{F_{x}}{F_{z0}})}^{2} - {(q_{Fcy} \frac{F_{y}}{F_{z0}})}^{2}\} \{(γ^{2} q_{Fz3} + q_{Fz1}) \frac{ρ_{z}}{R_{0}} + q_Fz2 \frac{ρ_{z}^{2}}{R_{0}^{2}}\} ({dp}_{i} p_{pFz1} + 1) F_{z0}$

Note that with this option selected for the normal force, the Pacejka effective radius formulation will also be used internally. This formulation is as follows [1]

$r_{eff} = r_Ω - F_{z0} \frac{F_{reff} \frac{F_{z}}{F_{z0}} + D_{reff} \arctan (B_{reff} \frac{F_{z}}{F_{z0}})}{C}$

$r_{Ω} = R_{0} (q_{reo} + q_{V1} {(R_{0} \frac{Ω}{V_{0}})}^{2})$

where the nominal load, $F_{z0}$ and the rest of the parameters used in these equations are defined in the tire parameters block.

Linear Spring-Damper

The Linear spring-damper option is the same formulation used for normal force calculation in the Linear and the Fiala tire components as explained below.

The tire loaded radius is calculated using the distance of the tire center from the surface, $rz$ (see Surface), and the inclination angle, $γ$ (see Tire Kinematics).

$r_{L} = \frac{rz}{\cos (γ)}$

Using a linear spring and saturated damping forces based on the tire compliance, the normal force, $F_{z}$ , is calculated as follows

$F_{z}^{C} = {\begin{array}{c} C (R_{0} - r_{L}) & r_{L} < R_{0} \\ 0 & otherwise \end{array}$

$F_{z}^{K} = {\begin{array}{c} K V_{z} & r_{L} < R_{0} \\ 0 & otherwise \end{array}$

$F_{z} = {\begin{array}{c} F_{z}^{C} + \min (F_{z}^{C}, F_{z}^{K}) & 0 < F_{z}^{C} + F_{z}^{K} \\ 0 & otherwise \end{array}$

where $V_{z}$ is the tire center speed with respect to ISO Z, $C$ is tire stiffness, $K$ is tire damping, and $R_{0}$ is tire unloaded radius. The use of the min function is to ensure that $F_{z}$ is continuous at $r_{L} = R_{0}$ .

With this option selected for $F_{z}$ , the user can choose between the tire unloaded radius, $R_{0}$ , and the loaded radius, $r_{L}$ , to assign to the effective radius, $r_{eff}$ .

Slip Calculations

Four options are available for tire slip calculation, Quasi-static, Constant time lags, Stretched string, and Damped transient.

Quasi-static

With the choice of Quasi-static, the following equations for longitudinal slip, $κ$ , and slip angle, $α$ , hold true on a flat surface with no inclination angle

$κ = {\begin{array}{c} \frac{Ω r_{e} - V_{x}}{|V_{x}|} & | V_{x} | > V_{x (\min)} \\ (Ω r_{e} - V_{x}) \frac{2 V_{x (\min)}}{V_{x}^{2} + V_{x (\min)}^{2}} & otherwise \end{array}$

$\tan (α) = {\begin{array}{c} \frac{V_{y}}{|V_{x}|} & | V_{x} | > V_{x (\min)} \\ V_{y} \frac{2 V_{x (\min)}}{V_{x}^{2} + V_{x (\min)}^{2}} & otherwise \end{array}$

where $r_{e}$ is the tire effective radius and considered equal to the loaded radius ( $r_{L}$ ), $Ω$ is the tire speed of revolution, $V_{x}$ and $V_{y}$ are the speeds of the tire center with respect to ISO X and ISO Y axes, respectively, and $V_{x (\min)}$ is the velocity threshold used for singularity avoidance in the slip calculations.

The longitudinal slip and slip angle are continuous and differentiable in the neighborhood of $V_{x} = 0$ .

	Constant Time Lags
	A first-order dynamics to the longitudinal slip and slip angle calculation can be introduced using the Constant time lags option. When active, the following slip formulation is used: $T_{long} \frac{d κ}{d t} = r_{e} Ω - V_{x} - κ \|V_{x}\|$ $T_{lat} (d \frac{\tan (α)}{d t}) = V_{y} - \tan (α) \|V_{x}\|$

Stretched String

With this option active, the relaxation lengths will be used in slip calculation as follows

$σ_{long} \frac{d κ}{d t} = r_{e} Ω - V_{x} - κ |V_{x}|$

$σ_{lat} (d \frac{\tan (α)}{d t}) = V_{y} - \tan (α) |V_{x}|$

where

$σ_{long} = \max (F_{z} (p_{Tx1} + p_{Tx2} {df}_{z}) \exp (p_{Tx3} {df}_{z}) (\frac{R_{0}}{F'_{z0}}) {LS}_{κ}, σ_{long}^{\min})$

$σ_{lat} = \max (p_{Ty1} \sin (2 \arctan (\frac{F_{z}}{p_{Ty2} F'_{z0}})) (1 - p_{Ty3} | γ |) R_{0} {LS}_{α}, σ_{lat}^{\min})$

Parameters in the above equations should be inserted using the GUI.

The load ratio, ${df}_{z}$ , is defined as

${df}_{z} = \frac{F_{z} - F_{z0}}{F_{z0}}$

Damped Transient

The implementation of this formulation is according to the section 7.2.2 of [1]. It is a semi-non-linear model that covers the non-linear range of the slip characteristics and also prevents undamped oscillations at low longitudinal speeds.

For the longitudinal deflection

$\frac{d u}{d t} = {\begin{array}{c} 0 & |V_{x}| < V_{low} \land A_{κ} κ_{sl} < κ' \land u \cdot (V_{sx} + |V_{x}| \frac{u}{σ_{κ}}) < 0 \\ - V_{sx} - |V_{x}| \frac{u}{σ_{κ}} & otherwise \end{array}$

where $V_{sx}$ is the $x$ -component of the slip velocity, $V_{low}$ is the velocity threshold, $A_{κ}$ is the parameter for the inequality, and $σ_{κ}$ is the longitudinal slip relaxation length. Moreover,

$κ' = u \frac{κ_{sl}}{σ_{κ}}$

$κ_{sl} = 3 \frac{D_{x}}{C_{F, κ}}$

$C_{F, κ} = B_{x} C_{x} D_{x}$

The following equation computes the longitudinal slip

$κ = κ' - k_{Vlow} \frac{V_{sx}}{C_{F, κ}}$

The low speed coefficient is calculated using the following equation

$k_{Vlow} = {\begin{array}{c} \frac{1}{2} k_{Vlow, 0} \cdot (1 + \cos (π \frac{|V_{x}|}{V_{low}})) & |V_{x}| < V_{low} \\ 0 & otherwise \end{array}$

Similarly, for the lateral deflection

$\frac{d v}{d t} = {\begin{array}{c} 0 & |V_{x}| < V_{low} \land α_{sl} < \tan_{α}' \land v \cdot (- V_{sy} + |V_{x}| \frac{v}{σ_{α}}) < 0 \\ V_{sy} - |V_{x}| \frac{v}{σ_{α}} & otherwise \end{array}$

$\tan_{α}' = \frac{v}{σ_{α}}$

$α_{sl} = 3 \frac{D_{y}}{C_{F, α}}$

$C_{F, α} = B_{y} C_{y} D_{y}$

$\tan_{α} = \tan_{α}' - V_{sy} \frac{k_{Vlow}}{C_{F, α}}$

The slip angle itself can be calculated from $\tan_{α}$ . This might not be necessary because the Pacejka 2012 formulation is based on $\tan_{α}$ .

Equations

The formulation for resultant forces/moments of tire-surface interaction at the tire contact patch are summarized below for the Pacejka 2012 tire component.

The longitudinal force is

$F_{x} = G_{x α} F_{x0}$

where

$F_{x0} = D_{x} \sin (C_{x} \arctan (B_{x} κ_{x} - E_{x} (B_{x} κ_{x} - \arctan (B_{x} κ_{x})))) + S_{Vx}$

$G_{x α} = \frac{1}{G_{x α 0}} \cos (C_{x α} \arctan (B_{x α} α_{S} - E_{x α} (B_{x α} α_{S} - \arctan (B_{x α} α_{S}))))$

The lateral force is

$F_{y} = F_{y0} G_{y κ} + S_{V κ}$

where

$F_{y0} = D_{y} \sin (C_{y} \arctan (B_{y} α_{y} - E_{y} (B_{y} α_{y} - \arctan (B_{y} α_{y})))) + S_{Vy}$

$G_{y κ} = \frac{1}{G_{y κ 0}} \cos (C_{y κ} \arctan (B_{y κ} κ_{S} - E_{y κ} (B_{y κ} κ_{S} - \arctan (B_{y κ} κ_{S}))))$

The normal force, $F_{z}$ , has been discussed in the Normal Force and Effective Radius section.

The overturning couple is

$\begin{array}{c} M_{x} = R_{0} F_{z} ( & q_{sx1} λ_{VMx} - q_{sx2} γ ({dp}_{i} p_{pM} x1 + 1) + q_{sx3} \frac{F_{y}}{F_{z0}} \\ + q_{sx4} \cos (q_{sx5} {\arctan (q_{sx6} \frac{F_{z}}{F_{z0}})}^{2}) \sin (q_{sx7} γ + q_{sx8} \arctan (q_{sx9} \frac{F_{y}}{F_{z0}})) \\ + q_{sx10} \arctan (q_{sx11} \frac{F_{z}}{F_{z0}}) γ) λ_{Mx} \end{array}$

The rolling resistance moment is

$M_{y} = F_{z} R_{0} (q_{sy1} + q_{sy2} \frac{F_{x}}{F_{z0}} + q_{sy3} | \frac{V_{x}}{V_{0}} | + q_{sy4} {(\frac{V_{x}}{V_{0}})}^{4} + (q_{sy5} + q_{sy6} \frac{F_{z}}{F_{z0}}) γ^{2}) ({(\frac{F_{z}}{F_{z0}})}^{q_{sy7}} {(\frac{p_{i}}{p_{io}})}^{q_{sy8}}) λ_{My}$

The self-aligning torque is

$M_{z} = M'_{z} + M_{zr} + s F_{x}$

where $M'_{z}$ is the torque due to pneumatic trail, $t$ , $M_{zr}$ is the residual torque, and $s F_{x}$ is the longitudinal force contribution to the self-aligning torque. Each of these terms has a specific expression, discussed in [1] in more detail.

All the employed parameters in the equations above need to be defined in the tire parameters block and be accessible to the Pacejka tire components.

Connections

Name	Description	Modelica ID
${frame}_{a}$	Multibody frame for tire center	frame_a
$Fz$	Signal output for the normal force	Fz
$LongSlip$	Signal output for longitudinal slip	LongSlip
$SlipAng$	Signal output for slip angle	SlipAng
$SpinRate$	Signal output for tire speed of revolution or spin rate	SpinRate
$r_{eff}$	Signal output for tire effective radius	r_eff
$IncAng$	Signal output for tire inclination angle or camber	IncAng
${en}_{in}$	[1] Vector input for surface normal vector	en_in
$r_{c}$	[1] Vector output for tire center position w.r.t. the inertial frame	r_c
${rz}_{in}$	[1] Signal input for tire center distance from the surface	rz_in
$p_{in}$	[2] Signal input for tire inflations pressure	p_in

[1] Available if Surface parameters Flat surface is false and Defined externally is true.

[2] Available if Pressure Override parameter is true and Constant Pressure is false.

Parameters

Inertia

Name	Default	Units	Description	Modelica ID
Override	$false$		True (checked) overrides the inertia parameters and enable the following two parameters	useInertia
$m$	$28$	$kg$	Tire mass	Mass
[I]	[1]	$kg m^{2}$	Rotational inertia, expressed in frame_a (center of tire)	Inertia

[1] $(\begin{array}{c} 0.78 & 0 & 0 \\ 0 & 1.56 & 0 \\ 0 & 0 & 0.78 \end{array})$

Initial Conditions

Name	Default	Units	Description	Modelica ID
Use Initial Conditions	$false$		True (checked) enables the following parameters	useICs
${IC}_{r, v}$	$Ignore$		Indicates whether to ignore, try to enforce, or strictly enforce the translational initial conditions	MechTranTree
${\overset{&conjugate0;}{r}}_{0}$	$[0, 0, 0]$	$m$	Initial displacement of frame_a (tire center) at the start of the simulation expressed in the inertial frame	InitPos
Velocity Frame	$Inertial$		Indicates whether the initial velocity is expressed in frame_a or inertial frame	VelType
${\overset{&conjugate0;}{v}}_{0}$	$[0, 0, 0]$	$\frac{m}{s}$	Initial velocity of frame_a (tire center) at the start of the simulation expressed in the frame selected in Velocity Frame	InitVel
${IC}_{θ, ω}$	$Ignore$		Indicates whether to ignore, try to enforce, or strictly enforce the rotational initial conditions	MechRotTree
$Quaternions$	$false$		Indicates whether the 3D rotations will be represented as a 4 parameter quaternion or 3 Euler angles. Regardless of setting, the initial orientation is specified with Euler angles.	useQuats
Euler Sequence	$[1, 2, 3]$		Indicates the sequence of body-fixed rotations used to describe the initial orientation of frame_a (center of mass). For example, [1, 2, 3] refers to sequential rotations about the x, then y, then z axis (123 - Euler angles)	RotType
${\overset{&conjugate0;}{θ}}_{0}$	$[0, 0, 0]$	$rad$	Initial rotation of frame_a (center of tire) at the start of the simulation (based on Euler Sequence selection)	InitAng
Angular Velocity Frame	$Euler$		Indicates whether the initial angular velocity is expressed in frame_a (body) or the inertial frame. If Euler is chosen, the initial angular velocities are assumed to be the direct derivatives of the Euler angles.	AngVelType
${\overset{&conjugate0;}{ω}}_{0}$	$[0, 0, 0]$	$\frac{rad}{s}$	Initial angular velocity of frame_a (center of tire) at the start of the simulation expressed in the frame selected in Angular Velocity Frame	InitAngVel

Settings

Name	Default	Units	Description	Modelica ID
${\overset{&Hat;}{e}}_{spin}$	$[0, 0, 0]$		Tire's spin axis (local)	SymAxis
$Side$	$0$		0: default, 1: mirrored	Side
$ISO$	$0$		0: Keep ISO, 1: Rotate ISO pi radians around Z axis	intISO
$F_{z}$	Pacejka formulation		Normal force equation (Pacejka formulation or Linear spring-damper)	FzMode
$r_{eff}$	Loaded radius		Effective radius (Loaded radius or Unloaded radius)	reffMode
$Slip$	Quasi-static		Choose type of slip calculation (Quasi-static, Constant time lags, Stretched string, or Damped transient)	slipMode
$T_{long}$	$0.3$	$s$	Time lag for longitudinal slip	TlongIn
$T_{lat}$	$0.3$	$s$	Time lag for slip angle	TlatIn
$Params$	[2]		Parameters for stretched-string formulation: [LSkappa, LSalpha, p_Tx1, p_Tx2, p_Tx3, p_Ty1, p_Ty2, p_Ty3]	ssParams
$σ_{{long}_{\min}}$	$0.1$		Minimum longitudinal relaxation length	TlongMin
$σ_{{lat}_{\min}}$	$0.1$		Minimum lateral relaxation length	TlatMin
$V_{low}$	$10$	$\frac{m}{s}$	Velocity threshold to add damping at lower speeds	V_low
$k_{Vlow0}$	$10000$	$\frac{N s}{m}$	Maximum damping value	k_V_low0
$A_{κ}$	$1$		Inequality constant for the longitudinal slip	A_kappa
$σ_{κ}$	$0.05$		Longitudinal slip relaxation length	sigma_kappa
$σ_{α}$	$0.05$		Side slip relaxation length	sigma_alpha

[2] $[1, 1, 2.3657, 1.4112, 0.56626, 2.1439, 1.9829, −0.90729]$

Pressure

Name	Default	Units	Description	Modelica ID
$Override$	$false$		True (checked) overrides override the pressure parameters and enables the following parameters	overridePressure
$p_{io}$	$2.2 \cdot 10^{5}$	$Pa$	Nominal tire pressure	over_p_io
$Constant pressure$	$true$		True (checked) uses constant pressure; false provides an input port for the tire pressure	isConstantPressure
$p_{i}$	$2.4 \cdot 10^{5}$	$Pa$	Tire pressure	over_p_cons

Scaling Factors

Name	Default	Units	Description	Modelica ID
$Override$	$false$		True (checked) override the scaling factors and enables the following parameter	overrideFactors
$λ_{Fz0}$	$1$		Nominal load scaling factor	over_lambda_Fz0
$λ_{mux}$	$1$		Peak friction coefficient (x) scaling factor	over_lambda_mux
$λ_{muy}$	$1$		Peak friction coefficient (y) scaling factor	over_lambda_muy
$λ_{muV}$	$0$		Slip speed decaying friction scaling factor	over_lambda_muV
$λ_{Kx κ}$	$1$		Brake slip stiffness scaling factor	over_lambda_KxKap
$λ_{Ky α}$	$1$		Cornering stiffness scaling factor	over_lambda_KyAlp
$λ_{Cx}$	$1$		Shape factor (x) scaling factor	over_lambda_Cx
$λ_{Cy}$	$1$		Shape factor (y) scaling factor	over_lambda_Cy
$λ_{Ex}$	$1$		Curvature factor (x) scaling factor	over_lambda_Ex
$λ_{Ey}$	$1$		Curvature factor (y) scaling factor	over_lambda_Ey
$λ_{Hx}$	$1$		Horizontal shift (x) scaling factor	over_lambda_Hx
$λ_{Hy}$	$1$		Horizontal shift (y) scaling factor	over_lambda_Hy
$λ_{Vx}$	$1$		Vertical shift (x) scaling factor	over_lambda_Vx
$λ_{Vy}$	$1$		Vertical shift (y) scaling factor	over_lambda_Vy
$λ_{Ky γ}$	$1$		Camber force stiffness scaling factor	over_lambda_KyGam
$λ_{Kz γ}$	$1$		Camber torque stiffness scaling factor	over_lambda_KzGam
$λ_{t}$	$1$		Pneumatic trail scaling factor	over_lambda_t
$λ_{Mr}$	$1$		Residual torque scaling factor	over_lambda_Mr
$λ_{x α}$	$1$		Alpha influence on $F_{x}$ (kappa) scaling factor	over_lambda_xAlp
$λ_{y κ}$	$1$		Kappa influence on $F_{y}$ (alpha) scaling factor	over_lambda_yKap
$λ_{Vy κ}$	$1$		Kappa induces ply-steer $F_{y}$ scaling factor	over_lambda_VyKap
$λ_{s}$	$1$		$M_{z}$ moment arm of $F_{x}$ scaling factor	over_lambda_s
$λ_{Cz}$	$1$		Radial tire stiffness scaling factor	over_lambda_Cz
$λ_{Mx}$	$1$		Overturning couple stiffness scaling factor	over_lambda_Mx
$λ_{My}$	$1$		Rolling resistance moment scaling factor	over_lambda_My
$λ_{VMx}$	$1$		Overturning couple vertical shift scaling factor	over_lambda_VMx

Surface

Name	Default	Units	Description	Modelica ID
Flat surface	$true$		True (checked) means the road surface is assumed flat. It is defined by a plane passing through (0,0,0) and the normal vector given by ${\overset{&Hat;}{e}}_{g}$	flatSurface
Defined externally	$false$		True (checked) means the road surface is defined external to the tire component. Additional input and output signal ports are activated.	externallyDefined
$δ_{L}$	$0.01$	$m$	Base distance for local surface patch approximation	deltaL
Data source	$inline$		Data source for the uneven surface. See following table.	datasourcemode
Surface data			Surface data; matrix or attached data set	table or data
Smoothness	$linear$		Smoothness of table interpolation	smoothness
$n_{Iter}$	$2$		Number of iterations to find the contact point candidate, recommended value between 1 and 5	nIter

Content of Data source matrix.

Surface normal	First Column	First Row
Global Z	x values	y values
Global Y	z values	x values
Global X	y values	z values

Visualization

Name	Default	Units	Description	Modelica ID
Show tire	$false$		True (checked) creates a tire visualization and enables following three parameters	showTire
$D_{w}$	$0.1$	$m$	Tire width (for visualization)	D_w
Tire color	$black$		Tire color	color00
Band color	$yellow$		Tire band color	color01
Tire transparency	$false$		True (checked) means the tire is transparent	transparent0
Show force arrow	$false$		True (checked) display a force vector and enables the following three parameters	showForceArrow
Show components	$false$		True (checked) means three arrows for force components in ISO axes will be shown instead of a single total force arrow	showForceComponents
Force arrow color	$red$		Specifies the color of the force arrow	color1
Force arrow transparency	$false$		True (checked means the force arrow is transparent	transparent1
Force arrow scale	$1$	$\frac{N}{m}$	Scales the length of the force arrow	scale1
Show torque arrow	$false$		True (checked) displays a torque vector and enables the following three parameters	showMomentArrow
Show components	$false$		True (checked) means three arrows for torque components in ISO axes will be shown instead of a single total torque arrow	showMomentComponents
Torque arrow color	$blue$		Specifies the color of the torque arrow	color2
Torque arrow transparency	$false$		True (checked) means the torque arrow is transparent	transparent2
Torque arrow scale	$1$	$\frac{N m}{m}$	Scales the length of the torque arrow	scale2
Show tangent plane	$false$		True (checked) displays the tangent plane of the contact patch and enables the following four parameters	ShowTanSurface
${th}_{0}$	$0.01$	$m$	Patch visualization thickness	th0
$r_{p}$	$0.2$	$m$	Patch visualization radius	r_patch
Patch color	Green		Color of the contact patch	color3
Patch transparency	$false$		True (checked) means contact patch is transparent	transparent3
Show ISO axis	$false$		True (checked) displays the ISO axes and enables the following two parameters	showISO
Axis scale	$1$	$m$	Length of each XYZ ISO axis in the visualization	scaleISO
Axis transparency	$true$		True (checked) means axes are transparent	transparentISO

Advanced Parameters

Name	Default	Units	Description	Modelica ID
$V_{x (\min)}$	$0.1$	$\frac{m}{s}$	Velocity threshold used for singularity avoidance in the slip calculations	V_x_min
$ε_{sgn}$	$0.001$		Used to smooth $sign (x)$ as $\tanh (\frac{x}{ε_{sgn}})$	epsilon_sign
$ε_{norm}$	$1 \cdot 10^{−8}$		Used to prevent singularity in vector normalization	epsilon_norm

References

[1] Pacejka, Hans. Tire and vehicle dynamics. Butterworth-Heinemann, 2012.

Maple

Erweiterungen für Maple

Student Success Platform

Verbesserung der Studienerfolgsquote

MapleSim

Erweiterungen für MapleSim

Systementwicklung

Beratende Dienstleistungen

Produkte zur Online-Ausbildung

Ausbildung

Industrie

Automobil und Luftfahrt

Robotik

Maschinendesign & industrielle Automation

Andere

Lösungen für die Industrie

Kaufen: Einzelheiten und Preise

Kaufen

Institutionelle Studentenlizenzierung

Elite-Wartungsprogramm

Support

Produktschulung

Online Hilfe zu Produkten

Webinare und Veranstaltungen

Veröffentlichungen

Content Hubs

Anwendungsbeispiele

Community

Über Maplesoft

Pressezentrum

User Community

Kontakt

Online Help

All Products Maple MapleSim

Maple

Leistungsfähige intuitive Mathematiksoftware

Erweiterungen für Maple

Student Success Platform

Verbesserung der Studienerfolgsquote

MapleSim

Modellierung auf Systemebene

Erweiterungen für MapleSim

Systementwicklung

Beratende Dienstleistungen

Produkte zur Online-Ausbildung

Ausbildung

Industrie

Automobil und Luftfahrt

Robotik

Maschinendesign & industrielle Automation

Andere

Lösungen für die Industrie

Kaufen: Einzelheiten und Preise

Kaufen

Institutionelle Studentenlizenzierung

Elite-Wartungsprogramm

Support

Produktschulung

Online Hilfe zu Produkten

Webinare und Veranstaltungen

Veröffentlichungen

Content Hubs

Anwendungsbeispiele

Community

Über Maplesoft

Pressezentrum

User Community

Kontakt

Online Help

All Products Maple MapleSim
